Holding the green grip on the left and the handle on the front, carefully insert the front end into the space horizontally. Do not remove the tape coming out of the unit. Remove all the orange tape from the drum unit. Do not move the drum unit by only holding the grip. When holding the drum unit, hold the green grip on the left and the handle on the front together. Take care that nothing comes into contact with the top surface of the drum unit. Do not remove the tape hanging from the front yet. Take the new yellow drum unit out of the box.įor black, install one black drum unit for color, install all three together.Įxposure to light reduces black drum unit/color drum units performance. Holding the green grip on the left and the handle on the front, pull out the drum unit.
Holding the handle, pull the drum unit out until the green grip area is completely visible on the left side. Pull out the ring pull handle of the yellow drum unit. From the left, the units are attached in the order of yellow (Y), cyan (C), magenta (M), and black (K). Pulling the handle, slowly open the inner cover.
Turn the two green levers counterclockwise. Holding the left and right side grips, carefully open the front cover. Turn off the printer and unplug the power cable.
